Modal Electronics 001

Hybrid Synthesizer

DescriptionImagesVideoTech specsCompatibleAlternativeFAQRelated ArticlesComments

001 1001 2001 3001 4
Product Images: click to view fullsize version.
Modal Electronics 001
Modal Electronics 001
1 900.00 street price

A 3-octave 001 is an analog/digital hybrid synthesizer made by Modal Electronics, a bi-timbral, duophonic instrument with velocity sensitive Fatar keyboard.

The 2-voice synthesizer provides you with discrete duophonic sound while each voice features two numerically controlled oscillators (so-called NCOs). Actually each voice sports 4 oscillators in the whole considering there are two sub-oscillators per voice as well, a dedicated LFO for each one and a global LFO. Numerically controlled sound generation ensures accuracy and stability. The unique way of oscillator control allows for precise high-resolution waveform variation while allocated LFOs enable flexible modulation.

The screen will react automatically to the knob tweak since the panel controls are touch sensitive and save you from menu diving.

Sequencing is versatile and full of capabilities owing to the 32-step sequencer (2 tracks, 12 rows). Every created sequence can be stored in a quick recall bank where favourite patches can be located as well allowing for using it as a setlist during live performances.

With a Hold function featured by a multi-mode arpeggiator it’s possible to apply sequencer and arpegiator together while the Animator function allows for sequencing any parameter including filter transitions, waveforms, and modulation.

The connectivity offers 2 audio inputs to process audio beginning with the filter stage.

All the updating is carried via the Ethernet port which makes the cloud system enabled. All can be updated through the cloud platform including patches, sequences and settings as well as quickly load the sounds or share your patches with anyone and edit them on your computer.

Tags: hybrid synthesizer

Favorites   Recommend product to a friend

E-mail*
More info

Usage area
Synthesizer
Usage Design/ Form Factor
With Keys
Archetype
Hybrid, Digital+Analog
Polyphony
Voices2
Voice Mode Mono
Voice Mode Poly
Voice Mode Chord
Multi Timbral Capacity2 part(s)
Tone Generator / Sound Synthesis
Oscillator Type NCO (Numerically Controlled Oscillator)
Oscillators per voice2
Sub-Oscillators per voice2
Filter
Voltage Controlled Filter (VCF)
High-pass Filter (HPF)
Low-pass Filter (LPF)
4-pole
24dB
Resonance
Envelope Generator (EG)
FilterADSR
AmpADSR
Delay+ADSR
Modulation
LFO: LFO Count3
LFO Self-oscillating LFO
Sequencer
Parts count12
Tracks count2
Max Step Count32
Arpegiator/ Portamento
Arpegiator
MIDI
General MIDI (GM)
MIDI in/ out
IN
OUT
THRU
Keys
Type Semi-weighted
Velocity Sensitivity
Aftertouch
Size3
Number of Keys37
Display
Color resolution 4096 colors/ 12bit
Resolution: Diagonal4.3
Built-in controllers
Joystick
External controllers
CV/ Gate IN
CV/ Gate OUT
Audio out
Stereo
All voices mixed in one output
Analogue: 1/4" (6.35mm)2
D-sub
Audio in
Analog 1/4"2
Computer Interfaces
Ethernet
USB USB PC Link
USB USB Storage
USB MIDI through USB
Power
Voltage 100-230(250)V
Voltage 50-60Hz
Power Supply Built-in, internal
Case/ body
Metal&wood
Color
White
Production start2014
